General Information
Standard features:
*Parison Clamp:
111 tons @ 2850PSI
*Availabe Casting Area:
63.3 sq. in. @ 3500 PSI
40.3 sq. in. @ 5500 PSI
*Blow Mold Clamp:
28 tons @ 2820 PSI
*Shut Height: 10' Std (254mm)
*Press Stroke: 6" Std (152mm)
*Standard Maxmium Die Set Size:
35.5' W x 19.0' L
(902mm x 483mm)
*Std. Distance between outside
cavity centerlines:
35.625' (904mm)
*Approximate Swing Radius:
34.5'(876mm)
*Approximate Container Size:
5.750" x 10' (146mm x 254mm)
*Shot Capacity:
V=Vertical or
H=Horizontal Reciprocal Screws:
270gr. (HDPE) w/2" (51mm)
dia. screw(24:1) (V)
360gr. (HDPE) w/2 1/2 "
(63mm) dia. screw (30:1) (V)
450gr. (HDPE) w/3" (76mm) dia.
screw (25:1) (V)
*225 gr. (PVC) w/2 1/2" (63mm)
dia/ screw (24:1) (V)
*Motor size Std. 75HP (56kw), *Motor size Opt. 100HP (75kw)
*Choice of Power Supply
Volts 380, Hz 50/60, Phase 3
Volts 415, Hz 50, Phase 3
Volts 460, Hz 60 Phase 3
Volts 600, Hz 60, Phase 3
*Recomended Power Service
200A @ 460 V
*Heat Zone 6
*Max. Total Heat Wattage
20.5kw; 25.9kw; 33.0kw
*Machine Dimensions
L 143' (3632mm) x W 84"
(2134mm)
H 2.5' (63.5 mm) 24:1 screw =
129' (3277mm)
2.5' (63.5mm) 30:1 screw =
149' (3786mm)
3.0" (76.2mm) 25:1 screw =
149'(3788mm)
*Installed Weight 27,000 tons
(12,720 kg)
