Screw Diameter:                                          26mm

Screw L/D Ratio:                                          18/1 L/D

Injection Stroke:                                           95mm

Injection Volume:                                        50 cm3

Injection Weight:                                         45.5 g

Injection Speed:                                           200 mm/s

Injection Pressure:                                     157 MPa

Holding Pressure:                                       125 MPa

Screw Speed:                                                 400 rpm

Nozzle Contact Force:                             26 kN

Nozzle in Size:                                               30mm

Clamping Force:                                          400 kN

Mold Opening Stroke:                               235 mm

Dist. Between Tie Bars:                           320 mm x 320mm

Min/Max Mold Dims:                                 205 mm x 205mm

Mold Height:                                                   150mm – 320mm

Ejector Stroke:                                               60mm

Ejector Force:                                                17.2 kN

Hopper Capacity:                                       15 L

Machine Dims:                                             3.7 x 1.3 x 1.9 Meters

Machine Weight:                                         6,000 lbs
